AIMA Big Sur Fat Tire Cruiser E-Bike
- All-Terrain Fat Tire Freedom
- 150+ km Per Charge
- Built On Bafang E-Bike System
Freedom Without Limits, Safety Without Compromise
BIG SUR lets you unleash the spirit of the wilderness onto a wider range of rugged terrain. Equally stable at high or low speeds, its powerful Bafang rear hub motor and high capacity 720Wh battery will provide you with a remarkably comfortable and smooth riding experience. A full UL2849 certification over the electric system guarantees the highest safety standard. The BIG SUR will take you anywhere you want to go.
Big Sur Full Specifications Breakdown
Features & Benefits
- Unique Step-Thru Aluminum frame with integral Smooth Welding
- Reliable Pedal Assist System, provided by Bafang
- Powerful Rear Hub Motor, 48V, 500W, Max Torque 80Nm
- High capacity Lithium-ion Battery, 48V, 15Ah (720Wh)
- Torque Sensor
- Integrated Driving Lights
- Shimano Drivetrain
- Tektro E-Brakes, Hydraulic, 203mm Rotors
- Full Length Fenders and Rear Rack included
Bike Specifications
Frame: Unique Step-Thru Hydroformed Aluminum alloy frame, Integral Smooth Welding, Internal Cable Routing,Integrated bearings, 100mm BSA, Replaceable forged alloy derailleur hanger
Fork: Zoom, 80mm travel Suspension Fork, Locking Lever, Spring Preload Adjustment
Stem: Forged Alloy, 1-1/8” Threadless
Handlebar: Alloy, Riser, Ø31,8mm, Width: 680mm
Grips: Comfort Ergo, Bolt-On
Seatpost: Alloy, Ø30.4mm Quick Release clamp
Saddle: Comfort Wide, Tear-Resistant, Integrated Springs and Lifting Handle
Shifters: Shimano Acera ST-M315, Rapidfire, 8 Speeds
Derailleur: Shimano Altus RD-M310, with Protecting Cage
Chainring: Direct Mount, Splined alloy spider, 52T
Cassette: Shimano HG, Megarange 11-34T
Chain: PYC, 1/2” x 3/32”
Pedals: Sure Grip Platform, Alloy, 9/16’’
Brakes: Tektro HD-E3520, Hydraulic Disc Brakes,with Power cut-off sensor
Rotors: Stainless Steel TR-52 Anti Vibration 203mm 6-Bolt rotors
Rims: 26’’, 36H, Wide Profile, Alloy, Schrader
Hubs: Front: Alloy, 135mm, Bolt-On, 6-Bolts Disc Mount, Rear: (See Motor)
Spokes: 13G Stainless Steel, Black
Tires: 26 x 4.0’’, Retro Tan Wall, Reflective Side Strips, E-Bike Rated Casing
Driving Lights: Front: Big Headlight, White, 100 LUX, Connected to battery, Rear: Semi-Integrated Red LED driving light, Connected to battery
Accessories: Alloy Cargo Rack, SureFix System Full-wrapping Fenders, Direct Mount Alloy E-Bike rated Kickstand
Listed Weight: 82 lbs (37 kg)
Max Payload: 400 lbs (180 kg)
Specifications are subject to change without notice. Most current and updated information is always available on AIMA E-Bikes Canadian website (www.aimamobility.ca)
Listed weights are based off pre-production bikes and may vary in production.
Pedal Assist System
Motor: Bafang G0270 48V Custom Brushless Rear Hub, 500W, 36H*13G
Battery: Bafang BT F400, Semi-Integrated, 720Wh Capatity Lithium-ion, High Performance LG cells
Display: Bafang DP C271.CAN New Generation Smart Color Backlit LCD, G5.4, IP65 Connector
Sensor: Bafang SR PA242 Torque Sensor, JIS Bottom Bracket, BSA External Cups
Throttle: On Demand Thumb Press Button, Integrated Electronic Horn Button
Controls: Power / PAS level control pad
Charger: AIMA 48V Fast Charge
Certifications
- Class 2 E-Bike, 500W (Software Restricted), 32km/h max assist.,
- UL 2849
- ISO 4210
